CompoNet input unit, 16 x 24 VDC inputs, NPN, vertical model, MIL Connector (not included)

Appendant operation agent (Ex ia)

FALSE

Appendant operation agent (Ex ib)

FALSE

Degree of protection (IP)

IP20

Depth

78.7 mm

Explosion safety category for dust

None

Explosion safety category for gas

None

Fieldbus connection over separate bus coupler possible

FALSE

Front built-in possible

FALSE

Height

120 mm

Input current at signal 1

6 mA

IO link master

FALSE

Number of digital inputs

16

Number of digital outputs

0

Number of HW-interfaces industrial Ethernet

0

Number of HW-interfaces other

1

Number of HW-interfaces parallel

0

Number of HW-interfaces RS-232

0

Number of HW-interfaces RS-422

0

Number of HW-interfaces RS-485

0

Number of HW-interfaces serial TTY

0

Number of HW-interfaces USB

0

Number of HW-interfaces Wireless

0

Number of interfaces PROFINET

0

Output current

-8888 A

Performance level according to EN ISO 13849-1

Level a

Permitted voltage at input

0-26.4 V

Permitted voltage at output

0-0 V

Rack-assembly possible

FALSE

Radio standard Bluetooth

FALSE

Radio standard GPRS

FALSE

Radio standard GSM

FALSE

Radio standard UMTS

FALSE

Radio standard Wi-Fi 802.11

FALSE

Rail mounting possible

TRUE

Short-circuit protection, outputs available

FALSE

SIL according to IEC 61508

None

Suitable for safety functions

FALSE

Supply voltage AC 50 Hz

0-0 V

Supply voltage AC 60 Hz

0-0 V

Supply voltage DC

20.4-26.4 V

Supporting protocol for AS-Interface Safety at Work

FALSE

Supporting protocol for CAN

FALSE

Supporting protocol for Data-Highway

FALSE

Supporting protocol for DeviceNet

FALSE

Supporting protocol for DeviceNet Safety

FALSE

Supporting protocol for EtherNet/IP

FALSE

Supporting protocol for Foundation Fieldbus

FALSE

Supporting protocol for INTERBUS

FALSE

Supporting protocol for INTERBUS-Safety

FALSE

Supporting protocol for KNX

FALSE

Supporting protocol for LON

FALSE

Supporting protocol for MODBUS

FALSE

Supporting protocol for other bus systems

TRUE

Supporting protocol for PROFIBUS

FALSE

Supporting protocol for PROFINET CBA

FALSE

Supporting protocol for PROFINET IO

FALSE

Supporting protocol for PROFIsafe

FALSE

Supporting protocol for SafetyBUS p

FALSE

Supporting protocol for SERCOS

FALSE

Supporting protocol for SUCONET

FALSE

Supporting protocol for TCP/IP

FALSE

System accessory

FALSE

Time delay at signal exchange

1.5-1.5 ms

Type of digital output

None

Type of electric connection

Plug-in connection

Type of voltage (input voltage)

DC

Voltage type of supply voltage

DC

Width

21 mm

With optical interface

FALSE
