Импульсный источник питания серии S8VK, мощность 120 Вт, выходное напряжение 24 В, выходной ток 5 A, монтаж на DIN-рейку, клеммы Push-in, с покрытием

1st secondary output voltage

21.6-28 V

2nd secondary output voltage

0-0 V

3rd secondary output voltage

0-0 V

Built-in height

90 mm

Built-in width

55 mm

Degree of protection (IP)

IP20

Degree of protection (NEMA)

Other

Depth

90 mm

Direct mounting possible

FALSE

Height

90 mm

Max. output current 1

6 A

Max. output current 2

-8888 A

Max. output current 3

-8888 A

Modular version

FALSE

Nominal value output current 1

5 A

Nominal value output current 2

-8888 A

Nominal value output current 3

-8888 A

Nominal value output voltage 1

24 V

Nominal value output voltage 2

-8888 V

Nominal value output voltage 3

-8888 V

Output voltage stabilized

FALSE

Performance level according to EN ISO 13849-1

None

Power consumption

144.9 VA

Power output

120 W

Rail mounting possible

TRUE

Rated supply voltage at AC 50 Hz

100-240 V

Rated supply voltage at AC 60 Hz

100-240 V

Rated supply voltage at DC

90-350 V

Secondary voltage adjustable

TRUE

Short-circuit-proof

TRUE

SIL according to IEC 61508

None

Stabilized

TRUE

Suitable for safety functions

FALSE

Type of electric connection

Spring clamp connection

Voltage type of supply voltage

AC/DC

Wall mounting possible

FALSE

Width

55 mm

Width in number of modular spacings

3.1
