Интерфейсный модуль PROFINET для системы ввода/вывода NX, 2 порта RJ-45, до 63 модулей ввода/вывода NX (512 байт для ввода, 512 байт для вывода). Максимальный ток вх/вых 10 А.
Промышленная сеть, децентрализованное периферийное устройство — основной прибор NX-PNC202, Omron
Модель: NX-PNC202
Производитель: Omron
41 400 ₽
Appendant operation agent (Ex ia)
FALSE
Appendant operation agent (Ex ib)
FALSE
Degree of protection (IP)
IP20
Depth
71 mm
Explosion safety category for dust
None
Explosion safety category for gas
None
Fieldbus connection over separate bus coupler possible
TRUE
Front built-in possible
FALSE
Height
100 mm
Input voltage at AC 50 Hz
0-0 V
Input voltage at AC 60 Hz
0-0 V
Input voltage at DC
20.4-26.4 V
IO link master
FALSE
Max. input current AC 50 Hz
0 A
Max. input current AC 60 Hz
0 A
Max. input current DC
10 A
Max. output current AC 50 Hz
0 A
Max. output current AC 60 Hz
0 A
Max. output current DC
10 A
Number of HW-interfaces industrial Ethernet
2
Number of HW-interfaces other
1
Number of HW-interfaces parallel
0
Number of HW-interfaces RS-232
0
Number of HW-interfaces RS-422
0
Number of HW-interfaces RS-485
0
Number of HW-interfaces serial TTY
0
Number of HW-interfaces USB
0
Number of HW-interfaces Wireless
0
Number of interfaces PROFINET
2
Number of slots
63
Output voltage at AC 50 Hz
0-0 V
Output voltage at AC 60 Hz
0-0 V
Output voltage at DC
20.4-26.4 V
Rack-assembly possible
FALSE
Radio standard Bluetooth
FALSE
Radio standard GPRS
FALSE
Radio standard GSM
FALSE
Radio standard UMTS
FALSE
Radio standard Wi-Fi 802.11
FALSE
Rail mounting possible
TRUE
Suitable for safety functions
FALSE
Supporting protocol for AS-Interface Safety at Work
FALSE
Supporting protocol for ASI
FALSE
Supporting protocol for CAN
FALSE
Supporting protocol for Data-Highway
FALSE
Supporting protocol for DeviceNet
FALSE
Supporting protocol for DeviceNet Safety
FALSE
Supporting protocol for EtherNet/IP
FALSE
Supporting protocol for Foundation Fieldbus
FALSE
Supporting protocol for INTERBUS
FALSE
Supporting protocol for INTERBUS-Safety
FALSE
Supporting protocol for KNX
FALSE
Supporting protocol for LON
FALSE
Supporting protocol for MODBUS
FALSE
Supporting protocol for other bus systems
FALSE
Supporting protocol for PROFIBUS
FALSE
Supporting protocol for PROFINET CBA
FALSE
Supporting protocol for PROFINET IO
TRUE
Supporting protocol for PROFIsafe
FALSE
Supporting protocol for SafetyBUS p
FALSE
Supporting protocol for SERCOS
FALSE
Supporting protocol for SUCONET
FALSE
Supporting protocol for TCP/IP
TRUE
System accessory
FALSE
Type of electric connection
Spring clamp connection
Type of output voltage
DC
Type of voltage (input voltage)
DC
Wall mounting/direct mounting
FALSE
Width
46 mm
With bus coupler for modular station connection
TRUE
With integrated power supply
FALSE
With optical interface
FALSE
With pluggable modules, analogue I/O
FALSE
With pluggable modules, central modules
FALSE
With pluggable modules, communication modules
FALSE
With pluggable modules, digital I/O
FALSE
With pluggable modules, function and technology modules
FALSE
With pluggable modules, others
FALSE
With potential separation
TRUE
