Модуль расширения для CJ1, 32 входа и 32 выхода (TTL-сигнал, 5VDC), 2 x MIL-разъем (поставляется отдельно)

Appendant operation agent (Ex ia)

FALSE

Appendant operation agent (Ex ib)

FALSE

Depth

83.6 mm

Digital inputs configurable

TRUE

Digital outputs configurable

FALSE

Explosion safety category for dust

None

Explosion safety category for gas

None

Height

90 mm

Input current at signal 1

3.5 mA

Number of digital inputs

32

Number of digital outputs

32

Output current

0.035 A

Performance level according to EN ISO 13849-1

Level a

Permitted voltage at input

4.5-5.5 V

Permitted voltage at output

4.5-5.5 V

Redundancy

FALSE

Short-circuit protection, outputs available

FALSE

SIL according to IEC 61508

None

Suitable for safety functions

FALSE

Supply voltage AC 50 Hz

0-0 V

Supply voltage AC 60 Hz

0-0 V

Supply voltage DC

12-24 V

Time delay at signal exchange

0-32 ms

Type of digital output

Transistor

Type of electric connection

Flat plug-in connection

Type of output voltage

DC

Type of voltage (input voltage)

DC

Voltage type of supply voltage

DC

Width

31 mm
