Интерфейсный модуль EtherNet/IP для системы ввода/вывода NX, 2 порта RJ-45, до 63 модулей ввода/вывода NX (512 байт для ввода, 512 байт для вывода). Максимальный ток вх/вых 10 А.

Appendant operation agent (Ex ia)

FALSE

Appendant operation agent (Ex ib)

FALSE

Degree of protection (IP)

IP20

Depth

71 mm

Explosion safety category for dust

None

Explosion safety category for gas

None

Fieldbus connection over separate bus coupler possible

TRUE

Front built-in possible

FALSE

Height

100 mm

Input voltage at DC

20.4-26.4 V

IO link master

FALSE

Max. input current DC

4 A

Max. output current DC

4 A

Number of HW-interfaces industrial Ethernet

2

Number of HW-interfaces other

1

Number of HW-interfaces parallel

0

Number of HW-interfaces RS-232

0

Number of HW-interfaces RS-422

0

Number of HW-interfaces RS-485

0

Number of HW-interfaces serial TTY

0

Number of HW-interfaces USB

0

Number of HW-interfaces Wireless

0

Number of interfaces PROFINET

0

Number of slots

63

Output voltage at DC

20.4-26.4 V

Performance level according to EN ISO 13849-1

Level a

Rack-assembly possible

FALSE

Radio standard Bluetooth

FALSE

Radio standard GPRS

FALSE

Radio standard GSM

FALSE

Radio standard UMTS

FALSE

Radio standard Wi-Fi 802.11

FALSE

Rail mounting possible

TRUE

SIL according to IEC 61508

None

Suitable for safety functions

FALSE

Supporting protocol for AS-Interface Safety at Work

FALSE

Supporting protocol for ASI

FALSE

Supporting protocol for CAN

FALSE

Supporting protocol for Data-Highway

FALSE

Supporting protocol for DeviceNet

FALSE

Supporting protocol for DeviceNet Safety

FALSE

Supporting protocol for EtherNet/IP

TRUE

Supporting protocol for Foundation Fieldbus

FALSE

Supporting protocol for INTERBUS

FALSE

Supporting protocol for INTERBUS-Safety

FALSE

Supporting protocol for KNX

FALSE

Supporting protocol for LON

FALSE

Supporting protocol for MODBUS

FALSE

Supporting protocol for other bus systems

FALSE

Supporting protocol for PROFIBUS

FALSE

Supporting protocol for PROFINET CBA

FALSE

Supporting protocol for PROFINET IO

FALSE

Supporting protocol for PROFIsafe

FALSE

Supporting protocol for SafetyBUS p

FALSE

Supporting protocol for SERCOS

FALSE

Supporting protocol for SUCONET

FALSE

Supporting protocol for TCP/IP

FALSE

System accessory

FALSE

Type of electric connection

Spring clamp connection

Type of output voltage

DC

Type of voltage (input voltage)

DC

Wall mounting/direct mounting

FALSE

Width

46 mm

With bus coupler for modular station connection

TRUE

With integrated power supply

FALSE

With optical interface

FALSE

With pluggable modules, analogue I/O

FALSE

With pluggable modules, central modules

FALSE

With pluggable modules, communication modules

FALSE

With pluggable modules, digital I/O

FALSE

With pluggable modules, function and technology modules

FALSE

With pluggable modules, others

FALSE

With potential separation

TRUE
